LTE+ Kit

XM16 LTE+ Kit — 5 modems

Turnkey LTE+ proxy farm with faster speeds and external antennas for tougher signal areas.

Turnkey 4G+ LTE Advanced kit with server, modems, hubs & cables included
CAT12 speeds up to 600 Mbps with 3C Carrier Aggregation
Worldwide cellular coverage across Americas, Europe, Asia & Africa
Native SOCKS5, HTTP(S), VLESS (REALITY) & VPN protocol routing

Kit size (modems)

Software

Compare all features ↗

Hardware (5 modems)$640.00

Software · selectedFree plan

Total today$640.00

SIM cards not included

* Shipping calculated at checkout Shipping policy

● Pre-order

Pre-order item: not in stock yet. Ask our sales team for the expected ship date.

Live demo Build your kit

12-month hardware warranty
Ships worldwide in 3–7 business days
Free lifetime tech support
Pay with crypto or arrange it with sales

Overview

LTE Advanced (LTE+) dongle kit with 3C/4C Carrier Aggregation and certified global coverage across the Americas (USA, Canada, Brazil), Europe (UK, Germany, France), Asia (Japan, South Korea, Vietnam), and Africa (South Africa, Nigeria, Kenya).

XM16 is the LTE Advanced step up from the entry LTE dongle kit. It delivers true global cellular coverage across Asia, Europe, the Americas, and Africa, engineered for operators who need stronger signal handling, faster speeds, and room to scale.

Use XM16 when your farm needs more durable LTE performance with Carrier Aggregation and external antenna support across diverse mobile carrier networks worldwide.

See it in action

Real hardware and the real dashboard, in a short silent loop.

Every SIM is its own mobile IP
Rotate any IP in seconds
All your modems in one dashboard

Demo data

Built around real mobile IPs

What this hardware does for your proxy farm.

Real mobile IPs

Every SIM you add gives you a real carrier IP, not a datacenter address.

Rotate in seconds

A hardware reset swaps the IP in about 3–5 seconds, on demand or on a timer.

One dashboard

Every modem, proxy and setting is managed from one web dashboard.

XH22 · 4G150 Mbps

XM16 · LTE+600 Mbps

XM55 · 5G2.5 Gbps

Rated maximum

Pick your speed

Rated up to 600 Mbps on this model. Real-world speed depends on your carrier and signal.

Performance & connectivity

Turnkey 4G+ LTE Advanced kit with server, modems, hubs & cables included
CAT12 speeds up to 600 Mbps with 3C Carrier Aggregation
Worldwide cellular coverage across Americas, Europe, Asia & Africa
Native SOCKS5, HTTP(S), VLESS (REALITY) & VPN protocol routing

Operation with XPROXY

Automatic proxy generation from connected modems
IP rotation, HTTP/SOCKS5, IPv4/IPv6 support
Manage every modem from one web dashboard

Built for production proxy farms

Every detail tuned for uptime, throughput and operator sanity.

📶

Network ready

Turnkey 4G+ LTE Advanced kit with server, modems, hubs & cables included

🔁

Live control

CAT12 speeds up to 600 Mbps with 3C Carrier Aggregation

⚡

Fast deploy

Worldwide cellular coverage across Americas, Europe, Asia & Africa

🛡️

Stable ops

Native SOCKS5, HTTP(S), VLESS (REALITY) & VPN protocol routing

Specs at a glance

The numbers that matter. The full spec sheet is below.

Network4G+ LTE-A CAT12
Speed600 MbpsRated maximum
Bands19 FDD · 5 TDD
SIMSIM (2FF)
Antennas2× external
ConnectionUSB 3.0

Technical specifications

Full hardware spec sheet. Need something custom? Talk to our team.

Network Class4G+ LTE Advanced CAT12

Modem ChipsetQualcomm Snapdragon LTE Advanced (CAT12)

4G FDD-LTE BandsB1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B18, B19, B20, B26, B28, B29 (DL), B30, B32 (DL), B66

4G TDD-LTE BandsB41, B42, B43, B46, B48

3G WCDMA / HSPA+B1, B2, B3, B4, B5, B6, B8, B9, B19

Regional CoverageAmericas (USA, Canada, Mexico, Brazil), Europe (UK, Germany, France, Spain, Italy), Asia (Japan, South Korea, India, Singapore, Vietnam), Africa (South Africa, Nigeria, Kenya, Egypt)

Protocols SupportedSOCKS5, HTTP(S), VLESS (REALITY), WireGuard & OpenVPN

Carrier Aggregation3C / 4C CA (Up to 600 Mbps DL)

Modem Hardware5x XM16 LTE Advanced CAT12 Dongles (Dual External Antennas, SOCKS5/VLESS/VPN)

SIM Card SlotStandard SIM (2FF Industrial Tray)

Server PlatformPre-configured XProxy Server Node

USB InfrastructureIndustrial USB 3.0 Powered Hubs (Sipolar)

Power Delivery12V Dedicated Industrial PSU (1.5A per port)

Software IncludedXProxy OS Lifetime Free Plan Installed

Capacity Sizing5 Dedicated Mobile Proxy Lines

Warranty & Support12 Months Complete Hardware Warranty

Hardware Band LockingSupported via XProxy Dashboard (Lock B1, B2, B3, B4, B7, B66, etc.)

Antennas IncludedDual External High-Gain Antennas per Modem Included

What's in the box

Tap a number to see the part. The render shows a 5-modem kit; your size changes the counts.

XM16 LTE+ Kit — 5 modems: everything in the box, laid out flat

5xXM16 LTE Advanced CAT12 Dongle (SOCKS5, VLESS, VPN)
1xXB26 Tiny Server (Pre-configured)
1x10-Port Industrial USB 3.0 Hub
1xXPROXY OS Software Pre-installed & Configured
1xPower Adaptors & Cabling Accessories Pack

SIM cards not included

Set up in 3 steps

Plug it in, power it on, check the lights. The 3D guide shows every cable.

Open the 3D setup guide →Not sure which kit? Compare kits

Built for

Higher-volume social and automation teams
Locations where signal quality varies by carrier
Long-running mobile proxy deployments
Scaling beyond basic LTE dongle kits

How to choose this model

Quick buying guidance before you pick capacity and software.

Choose this model when its capacity, connectivity, and deployment style match your proxy workload.

Not sure which kit? Compare kits →

Frequently asked

Quick answers about ordering, shipping and operating the XM16 LTE+ Kit — 5 modems.

Which frequency bands and countries does the XM16 Kit support?

The XM16 Kit delivers true global coverage with support for 19 FDD bands (B1–B32, B66), 5 TDD bands (B41–B48 incl. CBRS), and 9 3G bands. It works natively across the Americas (USA, Canada, Mexico, Brazil), Europe (UK, Germany, France, Spain, Poland), Asia (Japan, South Korea, India, Singapore, Vietnam), Africa (South Africa, Nigeria, Kenya), and Oceania (Australia, New Zealand).

Why choose XM16 instead of XH22?

XM16 is the better fit when signal quality, LTE+ performance, and long-running stability matter more than lowest entry cost.

What kind of workloads fit XM16?

XM16 fits medium or growing proxy farms that need dependable connections for social automation, scraping, QA, or resale operations.

Does XM16 replace 5G hardware?

No. XM16 is an LTE Advanced option. Choose XM55 or XCPE when your workload specifically needs 5G bandwidth or LAN-style 5G hardware.

Can sales help size the kit?

Yes. Use the sales CTA if you are unsure about carrier mix, modem count, or software tier.

How long does delivery take?

Orders usually ship worldwide in 3–7 business days with DHL, UPS or FedEx. Any remote-area surcharge is shown at checkout before you pay.

What is in the box?

Everything you need to go live: the modems, a pre-configured XProxy server, USB hubs or a network switch, power adapters and cables, with XProxy OS installed. The exact list for your size is under "What's in the box" above.

Are SIM cards included?

No. The modems are carrier-unlocked, so you can use any local data SIM. SIM cards are not included.

What warranty and support do I get?

Every kit comes with a 12-month hardware warranty and free lifetime tech support.

How can I pay?

Pay with crypto (USDT or USDC) at checkout, or ask our sales team to arrange another payment method.
